Installing or expanding a water filtration system should support your operation … not slow it down.
Foodservice facilities depend on a reliable supply of filtered water for beverages, ice, food preparation and other water-using equipment. As demand grows, however, a filtration system that was adequate at installation may eventually become a limitation. Service requirements, difficult filter changes and limited expansion options can all create unnecessary disruption.
The Aquamor Ultrafiltration System was developed with a more flexible approach. Its modular configuration allows businesses to select a system that fits their current flow requirements while providing practical options for increasing capacity as operations grow.
What Is Ultrafiltration?
Ultrafiltration, commonly called UF, is a membrane-filtration process. Water is pushed through a membrane that physically separates targeted suspended material and microorganisms according to their size.
Unlike reverse osmosis, ultrafiltration is not primarily intended to remove dissolved minerals or significantly alter the mineral composition of the water. Instead, it provides a mechanical barrier designed to reduce particulates and microorganisms while maintaining useful water flow.
For foodservice operators, this makes UF particularly valuable in applications where dependable mechanical filtration and higher flow rates are important.
Built Around the Needs of Growing Operations
Water demand rarely remains static. A restaurant may add another ice machine. A commercial kitchen may expand production. A multi-equipment installation may need to serve additional beverage, drinking-water or food-preparation applications.
Replacing an entire filtration platform whenever demand increases can be expensive and disruptive. A modular system provides a more adaptable path.
The Aquamor UF family includes configurations with maximum rated flow rates from 8 GPM to 30 GPM, allowing a system to be selected around the needs of the facility.
Available configurations include:
- The UF-4210-0000, item 108037, with a maximum flow rate of 8 GPM.
- The UF-4220-0000, item 108038, with a maximum flow rate of 15 GPM.
- The UF-4410-0000, item 108039, with a maximum flow rate of 15 GPM.
- The UF-4420-0000, item 108036, with a maximum flow rate of 30 GPM.
This range helps facilities avoid both undersizing and unnecessary oversizing. A smaller installation can begin with a configuration that matches current usage, while a higher-capacity configuration can support more demanding applications.
Faster, More Practical Membrane Service
Routine service is an unavoidable part of any filtration program, but the system’s design can make that service either straightforward or unnecessarily time-consuming.
Aquamor’s UF platform is designed to simplify access to the membrane assemblies. This can make planned change-outs and maintenance easier for service personnel while reducing the amount of time the filtration equipment is unavailable.
Potential operational advantages include:
- Quicker membrane change-outs
- Less complicated routine servicing
- Reduced maintenance downtime
- Easier access for inspection and replacement
- More predictable preventive-maintenance planning
The objective is not simply to make the filter easier to replace. It is to help the entire operation return to normal service sooner.
Multiple Configurations for Different Flow Requirements
Not every foodservice location has the same water demand. The Aquamor UF lineup addresses this by offering both single- and dual-membrane configurations.
20-Inch Single System
The UF-4210-0000, item number 108037, uses one 20-inch membrane and is rated for a maximum flow of 8 GPM. It can be considered for smaller installations or applications with moderate flow requirements.
Dual 20-Inch System
The UF-4220-0000, item number 108038, uses two 20-inch membranes and provides a maximum flow rate of 15 GPM.
40-Inch Single System
The UF-4410-0000, item number 108039, uses one 40-inch membrane and is also rated for a maximum flow of 15 GPM.
Dual 40-Inch System
For higher-demand applications, the UF-4420-0000, item number 108036, uses two 40-inch membranes and provides a maximum flow rate of 30 GPM.
All four listed models use standard 1-inch and 3/4-inch MNPT inlet and outlet connections.
Because actual system performance depends on incoming water conditions, pressure, plumbing design and simultaneous equipment demand, final sizing should be completed with assistance from a qualified water-treatment professional.
Reliable Mechanical Reduction
According to Aquamor’s published performance data, the UF system achieved an average cyst reduction of 99.99% under the specified test conditions.
This type of mechanical filtration can help provide an additional barrier against targeted microorganisms and suspended material. However, UF should be selected as part of a complete water-treatment strategy.
Incoming water conditions may also require additional treatment for concerns such as:
- Chlorine or chloramine taste and odor
- Sediment loading
- Scale-forming minerals
- Dissolved solids
- Iron or other location-specific water conditions
A water analysis and an evaluation of the connected equipment can help determine whether UF should be used alone or as one stage within a broader treatment system.
Know the Operating Requirements
Proper system selection also means confirming that the facility can operate within the manufacturer’s published parameters.
The Aquamor UF system is specified for:
- Minimum pressure: 20 PSI
- Maximum pressure: 100 PSI
- Minimum water temperature: 40°F
- Maximum water temperature: 100°F
- pH range: 3–10
- Maximum transmembrane pressure: 45 PSI
Operating outside the recommended range may affect flow, filtration performance or membrane life. Feed-water quality, pressure variations and usage patterns should therefore be reviewed before installation.
Less Time Servicing Equipment, More Time Serving Customers
Filtration equipment is essential infrastructure, but it should not become the focus of the operation.
A thoughtfully sized and accessible system can help reduce service interruptions, simplify scheduled maintenance and support future capacity requirements. That means employees can spend less time responding to filtration problems and more time serving customers.
The Aquamor UF System offers several practical benefits:
✔ Quick membrane change-outs
✔ Multiple flow-rate configurations
✔ Modular options for growing operations
✔ Standard plumbing connection sizes
✔ Reduced maintenance disruption
✔ Reliable mechanical filtration
✔ Configurations supporting up to 30 GPM
Designed for Today and Ready for What Comes Next
The best filtration system is not merely one that meets today’s requirements. It should also provide a practical path for tomorrow.
Whether a facility is installing a new filtration system, replacing existing membrane equipment or preparing for increased water demand, Aquamor’s UF platform offers flexible configurations for a range of foodservice applications.
Explore the complete line in the Aquamor Foodservice Distribution Catalog or contact Aquamor for assistance evaluating water conditions, flow requirements and the appropriate system configuration.
Clean Water. Clear Dedication.
